CD74HC4067 Analog Digital Multiplexer Module – 16-Channel Breakout Board

Supercharge your microcontroller projects with the CD74HC4067 Analog Digital Multiplexer Module. Designed for seamless integration with popular platforms like Arduino, this versatile 16-channel breakout board dramatically enhances your input and output capabilities. Whether you're juggling multiple sensors, managing diverse signals, or optimizing complex data pathways, this high-performance multiplexer module is an essential addition to your electronics arsenal.

Why the CD74HC4067 Multiplexer Module is a Must-Have

The CD74HC4067 module distinguishes itself with exceptional functionality and user-friendly design, making it ideal for both hobbyists and professional engineers. Discover the features that make this multiplexer module a standout choice for your electronic projects:

Outstanding Features:

1. 16-Channel Switching: Seamlessly switch one common pin to any of the 16 available channels. This robust switching capability enables you to manage numerous inputs and outputs efficiently, eliminating the need for extra microcontroller pins.
2. Analog and Digital Support: Compatible with both analog sensors and digital signals, the CD74HC4067 offers full bidirectional functionality. This flexibility makes it perfect for a wide array of applications, from simple LED control systems to intricate data acquisition setups.
3. Effortless Control with 5 Pins: Featuring four digital output pins for address selection and a single enable pin, controlling the module is straightforward and efficient. This minimal pin requirement preserves your microcontroller’s resources for other critical tasks.
4. Versatile Signal Routing: Capable of handling various communication protocols, including TTL-level serial data, I2C, and SPI. This adaptability ensures the module integrates smoothly into diverse project configurations.
5. Low On-Resistance & Minimal Leakage: Engineered to maintain high signal integrity, the module provides low on-resistance and minimal leakage. This ensures reliable performance even in sensitive electronic applications.
6. Break-Before-Make Switching: The intelligent break-before-make mechanism disconnects the current channel before connecting to a new one, preventing crosstalk, enhancing signal clarity, and reducing interference.
7. Enable Pin Functionality: The enable pin allows you to disconnect the common pin from all channels when needed. This feature is invaluable for power management and maintaining signal integrity in multi-channel configurations.

Technical Specifications:

• Operating Voltage: Compatible with a wide voltage range between ground (GND) and VCC, making it suitable for various electronic components and sensors.
• Compact Form Factor: The sleek and compact breakout board design is perfect for projects with limited space, ensuring a tidy and efficient setup without compromising functionality.
• Control Interface: Equipped with four address pins (digital outputs) and an enable pin, the module offers a user-friendly and flexible control interface, facilitating easy integration into your existing systems.

Perfect for a Wide Range of Applications:

• Sensor Integration: Ideal for projects requiring multiple sensor inputs. Efficiently manage and switch between various sensors while conserving valuable microcontroller pins, enabling more complex and interactive designs.
• Signal Multiplexing: Effectively handle multiple analog or digital signals within a streamlined and compact system. Perfect for applications like audio signal routing, data acquisition, and more.
• Serial Data Management: Simplify the routing of TTL-level serial data between different devices, enhancing communication efficiency in projects involving multiple serial interfaces.
• Rapid Prototyping: Speed up your development process by easily managing numerous inputs and outputs, allowing you to focus on innovation and functionality without being limited by hardware constraints.

The CD74HC4067 Multiplexer Breakout Module is not just a component; it's a gateway to expanding the capabilities of your projects. By simplifying the management of multiple sensors and signals, it reduces the need for excessive I/O pins on your microcontroller, enabling more streamlined and efficient designs. Whether you're developing complex robotics, sophisticated data acquisition systems, or cutting-edge IoT solutions, this multiplexer module provides the flexibility and reliability you need to bring your ideas to fruition.

Upgrade Your Projects Today

Don’t let limited I/O capabilities restrict your creativity. Invest in the CD74HC4067 Analog Digital Multiplexer Module and elevate your microcontroller projects to new heights. With its robust features, versatile applications, and effortless integration, it's the perfect solution for engineers and makers aiming to maximize their project's potential. Add it to your cart now and experience the transformative impact it can have on your next electronic venture!
