Gigabyte B760M GAMING X DDR4 GEN5 Intel 1700 Socket Motherboard

Name: Gigabyte B760M GAMING X DDR4 GEN5 Intel 1700 Socket Motherboard
Brand: GIGABYTE
Price: 119.39 GBP
Availability: InStock

£119.39

(inc VAT)

Free Delivery: Friday 11th - Monday 14th.
If You Order In The Next 1hrs 35mins

Delivery and Shipping

Order Processing

Orders are typically dispatched within 1-3 working days.

Delivery Options

Royal Mail 48: £1.50 on orders up to £20.
Royal Mail Tracked 48: Free on orders over £20.
DPD Next Day: Free on orders over £50 or £6.99.
International Shipping: Available at checkout.

You’ll receive tracking details as soon as your order ships track your order here. For full details, please see our Shipping Policy.

Free Returns

Buy with confidence. If you're not completely satisfied with your purchase, you can return eligible items within 60 days of delivery. Products must be unused, in their original condition and packaging, and accompanied by proof of purchase.

No hassle if there's a problem. If your item arrives damaged, defective, or incorrect, simply get in touch and we'll work quickly to make it right.

Simple returns, fast refunds. Once your return has been received and inspected, approved refunds are issued to your original payment method. View our full Refund Policy for complete details and exclusions.

Gigabyte B760M GAMING X DDR4 GEN5 Intel 1700 Socket Motherboard

£119.39

B760M GAMING X DDR4 GEN5 Motherboard

The B760M GAMING X DDR4 GEN5 motherboard is designed for PCIe Gen5 performance, advanced thermal solutions, and versatile connectivity, supporting the latest Intel® desktop processors and high-speed DDR4 memory.

Key Features

PCIe Gen5 Performance
PCIe Gen5 support with perfect sync for winning performance
Processor Support
Supports Intel® Core™ 14th, 13th, and 12th Generation processors
Efficient Thermal Design
VRM Thermal Armor Advanced
M.2 Thermal Guard
EZ-Latch
PCIe 5.0 x16 slot with quick release design
PCIe UD Slot
SMD PCIe 5.0 armor for enhanced graphics card support
Unparalleled Power Performance
Hybrid 8+1+1 phases VRM solution
Dual Channel DDR4 Memory
4 DIMM slots with XMP memory module support
Fast Networking
2.5GbE LAN
Extended Connectivity
Front USB-C® 10Gb/s
DisplayPort and HDMI
Next Generation Storage
2 x PCIe 4.0 x4 M.2 connectors
Smart Fan 6
Multiple temperature sensors
Hybrid fan headers with FAN STOP
Q-Flash Plus
Update BIOS without installing CPU, memory, or graphics card

Specifications

CPU

Item	Details
Socket	LGA1700
Support	14th, 13th, and 12th Generation Intel® Core™, Pentium® Gold, and Celeron® Processors
Note	L3 cache varies with CPU (see GIGABYTE website for latest CPU support list)

Chipset

Item	Details
Chipset	Intel® B760 Express Chipset

Memory

Item	Details
Memory Type	DDR4
Supported Speeds (MT/s)	5333(O.C.) / 5133(O.C.) / 5000(O.C.) / 4933(O.C.) / 4800(O.C.) / 4700(O.C.) / 4600(O.C.) / 4500(O.C.) / 4400(O.C.) / 4300(O.C.) / 4266(O.C.) / 4133(O.C.) / 4000(O.C.) / 3866(O.C.) / 3800(O.C.) / 3733(O.C.) / 3666(O.C.) / 3600(O.C.) / 3466(O.C.) / 3400(O.C.) / 3333(O.C.) / 3300(O.C.) / 3200 / 3000 / 2933 / 2666 / 2400 / 2133
Slots	4 x DDR4 DIMM sockets
Max Capacity	Up to 128 GB (32 GB per DIMM)
Channel Architecture	Dual channel
ECC Support	ECC Un-buffered DIMM 1Rx8/2Rx8 modules (operate in non-ECC mode)
Non-ECC Support	Non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 modules
XMP	Support for Extreme Memory Profile (XMP) memory modules
Note	CPU and memory configuration may affect supported memory types, speed, and number of modules (see GIGABYTE “Memory Support List” for details)

BIOS

Item	Details
ROM	1 x 256 Mbit flash
Type	Licensed AMI UEFI BIOS
Standards	PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0

Graphics

Item	Details
Integrated Graphics	Intel® HD Graphics support
HDMI Port	1 x HDMI, max resolution 4096x2160 @ 60 Hz
HDMI Standard	HDMI 2.1, HDCP 2.3, native HDMI 2.1 TMDS compatible ports
DisplayPort	1 x DisplayPort, max resolution 4096x2304 @ 60 Hz
DisplayPort Standard	DisplayPort 1.2, HDCP 2.3

Audio

Item	Details
Codec	Realtek® Audio CODEC
Audio	High Definition Audio
Channels	2/4/5.1/7.1-channel (configurable via audio software)
Digital Output	Support for S/PDIF Out
Note	7.1-channel audio configurable in audio software; audio jack functions can be changed via software

LAN

Item	Details
LAN	Realtek® 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps)

Wireless LAN

Item	Details
WLAN	N/A

Expansion Slots

Source	Slot
CPU	1 x PCI Express x16 slot, PCIe 5.0, running at x16 (PCIEX16)*
Chipset	1 x PCI Express x16 slot, PCIe 3.0, running at x4 (PCIEX4)

* PCIEX16 supports either a graphics card or an NVMe SSD. For a single graphics card, install it in the PCIEX16 slot.

Storage

Source	Connector
CPU	1 x M.2 connector (Socket 3, M key, type 2280, PCIe 4.0 x4/x2 SSD support) (M2A_CPU)
Chipset	1 x M.2 connector (Socket 3, M key, type 22110/2280, PCIe 4.0 x4/x2 SSD support) (M2P_SB)
Chipset	4 x SATA 6Gb/s connectors

RAID

Item	Details
SATA RAID	RAID 0, RAID 1, RAID 5, RAID 10 support

USB

Source	Ports
Chipset	1 x USB Type-C® port with USB 3.2 Gen 2 support (via internal header)
	5 x USB 3.2 Gen 1 ports (3 x rear panel, 2 x internal header)
	1 x USB 2.0/1.1 port (rear panel)
Chipset + 2 USB Hubs	8 x USB 2.0/1.1 ports (4 x rear panel, 4 x internal headers)

Internal Connectors

1 x 24-pin ATX main power connector
1 x 8-pin ATX 12V power connector
1 x CPU fan header
3 x system fan headers
3 x addressable LED strip headers
1 x RGB LED strip header
2 x M.2 Socket 3 connectors
4 x SATA 6Gb/s connectors
1 x front panel header
1 x front panel audio header
1 x S/PDIF Out header
1 x USB Type-C® header with USB 3.2 Gen 2 support
1 x USB 3.2 Gen 1 header
2 x USB 2.0/1.1 headers
2 x Thunderbolt™ add-in card connectors
1 x Trusted Platform Module header (for GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0/GC-TPM2.0 SPI V2 module only)
1 x serial port header
1 x Q-Flash Plus button
1 x reset jumper
1 x Clear CMOS jumper
