Ubiquiti U7-PRO-XG UniFi 7 Pro XG Ceiling Mounted 6 Stream WiFi 7 6GHz 10GbE Access Point
£209.88
Ceiling-Mounted 6-Stream WiFi 7 Access Point with 10G Uplink
Deliver high-performance wireless connectivity with this ceiling-mounted WiFi 7 access point, designed with 6 spatial streams, 6 GHz support, and multi-gigabit Ethernet for demanding environments.
Key Features
- WiFi Standard: WiFi 7 (802.11be) with 6 GHz support
- Spatial Streams: 6
- Coverage Area: 140 m² (1,500 ft²)
- Max. Client Count: 300+ connected devices
- Uplink: 10 GbE RJ45 port
- Mounting Options: Ceiling, Wall (Lite Mount Included)
- Power Method: PoE+
- Wireless Meshing: Yes
- Advanced Roaming & Management: 802.11v, 802.11r, 802.11k, Advanced Radio Management
- Security & Control: Captive Hotspot Portal, PPSK, RADIUS over TLS (RadSec), Client Device Isolation, WiFi Speed Limiting, WiFi Schedules
- Certifications: CE, FCC, IC
Dimensions & Physical
| Specification | Detail |
|---|---|
| Dimensions | Ø 206 x 32.5 mm (Ø 8.1 x 1.3") |
| Weight | 750 g (1.7 lb) |
| Enclosure Material | UV-stabilized polycarbonate, aluminum alloy |
| Mount Material | Stainless steel (SUS304), galvanized steel (SGCC) |
| LEDs | System |
Wireless Performance
MIMO Configuration
| Band | MIMO Configuration |
|---|---|
| 6 GHz | 2 x 2 (DL/UL MU-MIMO) |
| 5 GHz | 2 x 2 (DL/UL MU-MIMO) |
| 2.4 GHz | 2 x 2 (DL/UL MU-MIMO) |
Maximum Data Rates
| Band | Max. Data Rate |
|---|---|
| 6 GHz | 5.8 Gbps (BW320) |
| 5 GHz | 4.3 Gbps (BW240) |
| 2.4 GHz | 688 Mbps (BW40) |
Antenna Gain
| Band | Antenna Gain |
|---|---|
| 6 GHz | 6 dBi |
| 5 GHz | 5 dBi |
| 2.4 GHz | 4 dBi |
Max. TX Power
| Band | Max. TX Power |
|---|---|
| 6 GHz | 24 dBm |
| 5 GHz | 26 dBm |
| 2.4 GHz | 23 dBm |
Supported Data Rates
| Standard | Band / Data Rate Range |
|---|---|
| 802.11be (WiFi 7) | 6 GHz: 7.3 Mbps to 5.8 Gbps (MCS0 - MCS13 NSS1/2, EHT 20/40/80/160/320) |
| 5 GHz: 7.3 Mbps to 4.3 Gbps (MCS0 - MCS13 NSS1/2/3/4, EHT 20/40/80/160/240) | |
| 802.11ax (WiFi 6) | 7.3 Mbps to 2.4 Gbps (MCS0 - MCS11 NSS1/2, HE 20/40/80/160) |
| 802.11ac (WiFi 5) | 6.5 Mbps to 1.7 Gbps (MCS0 - MCS9 NSS1/2, VHT 20/40/80/160) |
| 802.11n | 6.5 Mbps to 300 Mbps (MCS0 - MCS15, HT 20/40) |
Channel Bandwidth Support
- HT 20/40 MHz
- VHT 20/40/80/160 MHz
- HE 20/40/80/160 MHz
- EHT 20/40/80/160/240/320 MHz
BSSIDs
- Up to 8 BSSIDs per radio
Advanced Wireless & Management Features
- Wireless Meshing
- Band Steering
- 802.11v BSS Transition Management
- 802.11r Fast Roaming
- 802.11k Radio Resource Management (RRM)
- Advanced Radio Management
- Passpoint (Hotspot 2.0)
- Captive Hotspot Portal
- Private Pre-Shared Key (PPSK)
- WiFi Speed Limiting
- Client Device Isolation
- WiFi Schedules
- RADIUS over TLS (RadSec)
Networking & Power
| Specification | Detail |
|---|---|
| Networking Interface | (1) 10 GbE RJ45 port |
| Power Method | PoE+ |
| Max. Power Consumption | 22 W |
| Supported Voltage Range | 42.5 – 57 V DC |
| Management | Ethernet |
Certifications
- CE
- FCC
- IC
